INTELLIGENT GAS FILLING & PRECISE ASSEMBLY

The line automatically detects glass size, glass thickness, and spacer thickness to create an optimized gas filling chamber for each insulated glass unit. This maximizes argon utilization, reduces gas consumption, and ensures reliable filling performance without damaging the spacer system. The high-tech press machine uses a 3 or 4-axis servo linkage system for accurate assembly, gas filling, and pressing, supporting double, triple, and stepped IG units with consistent quality.

SMART WASHING & ENERGY-SAVING OPERATION

Equipped with a PLC control system and touch screen interface, the line offers smooth, user-friendly operation and excellent washing performance for on-line and off-line Low-E glass. It features automatic air knife adjustment according to glass thickness, inverter-controlled Low-E brush rotation, automatic glass positioning, optional spacer frame positioning, and an optimized intermittent working system to improve energy efficiency and production reliability.

Technical data

• Max. glass size: 2500 × 3000 mm / 2000 × 2500 mm
• Min. glass size: 300 × 450 mm
• Insulating glass thickness: 10 – 48 mm
• Washing glass thickness: 3 – 19 mm
• Washing speed: 0 – 10 m/min
• Low-E brush: 6 units / 3 units for Low-E
• Conveying speed: 45 m/min
• Press suction: 6 kg/EA
• Filling time: 3 – 5 seconds for 900 × 1200 mm
• Environment temperature: 7 – 50°C
• Power: 3P 380V / 1P+N 220V, 50Hz, 38kW
• Air source: 0.8 m³/min, 0.7 MPa
• Water conductivity: ≤30 μs/cm
